Outdoor Hexagon LED Display

Outdoor Hexagon LED Display

Application:
Outdoor
Color:
Full Color
Panel Size:
350MM
Pixel Pitch:
3.15625mm
  • Summary
  • Product Atlas
  • Specification table
  • Case
  • Summary
    ◎SMD technology provide much wider view angle, more excellent flatness and  stability
    ◎RGB Deep grey processing which provide rich color, high definition image quality
    ◎Color and brightness are with high-consistency by the point-by-point correction  fuction
    ◎Quick and accurate installation location type, suitable for many different  installation places
    ◎Inner fixed reinforcement plate, tensile and shockproof, auto heat dissipation,  make the operating life 10 years
    ◎Large scale production, adopt high-quality material, mature processing
    technology,
    which assure good and stable quality
    ◎Use excelllent quality aviation plug to assure safty and good quality
    © With complete series, customized items to reach many users different need
  • Product Atlas













  • Specification table
    Quick Details

    IP Rating:IP65
    Brightness Intensity:>5500CD/ ㎡
    Application:

    Outdoor
    Color:
    Full Color
    Panel Size:
    350MM
    Pixel Pitch:
    3.15625mm
    Place of Origin:
    Guangdong, China
    Model Number:
    HWY-PH3
    Brand Name:
    H&S
    Blind Spot Rate:
    < 2/10000
    Working Voltage:
    AC220V±15% 47~64HZ
    Maximum Power:
    300W/ pcs
    Average Power:
    120W/ pcs
    MTBF:
    >10000 Hours
    Life Time:
    >100000 Hours
    Warranty:
    2 Years
    Operating Temperature:
    -10℃~+60℃
    Operating Humidity:
    10%-95%RH
