IMG_4282

Indoor high definition LED dis

Main areas: public transport, transport, transport operators, fire, safety supervision
Seamless and lossless display
Seamless assembly on the whole screen, dot-to-dot fine display, ensuring accurate display of digital
signals, graphic signals and text information.
Video Surveillance
Massive video surveillance and key video surveillance triggers combined with led display to meet
daily calls and emergency command requirements

  • Summary
  • Product Atlas
  • Specification table
  • Case
  • Summary
     SMD three-in-one technology, which makes the screen have an ultra-wide viewing angle and better surface flatness and stability.

     RGB deep grayscale processing, rich colors, high quality HD

     Support point-by-point correction function to ensure the consistency of color and brightness during use

     Precise, fast and flexible positioning installation, which can effectively cope with different installation environments

    The inside of the screen body is fixed with reinforcing ribs, which are tensile and shockproof, self-heating, and have a life span of ten years.

     Large-scale production, mature technology, high-quality raw materials, stable and reliable quality

    The series is complete and can be customized to meet the different needs of customers.

  • Product Atlas







  • Specification table

    JY600 系列参数Panel Specification

    使用环境 Environmental

    INDOOR

    产品型号 Model

    JY600-0.93

    JY600-1.25

    JY600-1.56

    JY600-1.87

    像素间距 Pixel Pitch

    0.9375mm

    1.25mm

    1.5625mm

    1.875mm

    像素构成 LED Configuration

    SMD0808

    SMD1010

    SMD1010

    SMD1010

    像素密度 Pixel Density

    1137777dot/

    640000dot/

    409600dot/

    284444dot/

    模组尺寸 Module size

    150x168.75mm

    150x168.75mm

    150x168.75mm

    150x168.75mm

    模组分辨率 Module Resolution

    160x180dot

    120x135dot

    96x108dot

    80x90dot

    箱体尺寸 Cabinet Size

    600x337.5x38mm

         600x337.5x38mm          600x337.5x38mm

    600x337.5x38mm

    箱体分辨率 Cabinet Resolution

    640x360dot

    480x270dot

    384x216dot

    320x180dot

    重量 Cabinet Weight

    5kg

    5kg

    5kg

    5kg

    防水等级 IP Rating ( front/back)

    IP40

    IP40

    IP40

    IP40

    扫描方式 Scanning Mode

    60S

    45S

    36S

    30S

    亮度水 Brightness Intensity

    >450CD/

    >450CD/

    >450CD/

    >450CD/

    可视角度 Viewing Angle

    140°

    140°

    140°

    140°

    观看距离 View Distance

    >1m

    >1.3m

    >1.6m

    >1.9m

    灰度等级 Gray Scale

    16bit

    16bit

    16bit

    16bit

    色彩种类 Display Scale

    16.7M

    16.7M

    16.7M

    16.7M

    最大功率 Max.Power Consumption

    800W/m2

    800W/m2

    800W/m2

    800W/m2

    平均功率 Ave.Power Consumption

    265W/m2

    265W/m2

    265W/m2

    265W/m2

    刷新率 Refresh Frequency

    >3840HZ

    >3840HZ

    >3840HZ

    >3840HZ

    亮度调节 Brightness Adjustment

    0-100 levels adjustable

    控制方 Control Mode

    Synchronous display with control PC by DVI

    支持信号输入Support Input

    Com posite,S-Vido,Com ponent,VGA,DVI,H DMI,H D_S DI

    输入电源 Input Power

    AC100/240 50/60HZ

    工作温度 Operating Temperature

    -20°C~+50°C

    工作湿度 Operating Humidity

    10-90% RH

    工作寿命 Operating Life

    100,000hours
